Sanyo PLC HF10000L Service Manual

Key No. Part No. Description Key No. Part No. Description
KG2-HF10000L00
Electrical Parts List
-250-
X301 645 103 3079 OSC,CRYSTAL 36MHZ
X3201 645 103 3055 OSC,CRYSTAL 28.6363MHZ
X3401 945 076 5194 OSC,CRYSTAL 79.991883MHZ
X401 645 101 8625 OSC,CRYSTAL 33.3333MHZ
X5201 645 103 9279 OSC,CRYSTAL 82.0MHZ
AA6800 610 351 7261 ASSY,PWB,MAIN CONTROL.KG2A
TRANSISTOR
Q6801 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6802 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6803 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6804 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6806 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6807 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6808 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6809 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6811 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6816 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
RESISTOR
R6801 301 224 9019 MT-GLAZE 10K JA 1/16W
R6803 301 256 5614 MT-GLAZE 47 JA 1/10W
R6804 301 265 0211 MT-GLAZE 390 FA 1/10W
R6806 301 224 9019 MT-GLAZE 10K JA 1/16W
R6808 301 256 5614 MT-GLAZE 47 JA 1/10W
R6809 301 265 0211 MT-GLAZE 390 FA 1/10W
R6811 301 224 9019 MT-GLAZE 10K JA 1/16W
R6813 301 256 5614 MT-GLAZE 47 JA 1/10W
R6814 301 265 0211 MT-GLAZE 390 FA 1/10W
R6816 301 224 9019 MT-GLAZE 10K JA 1/16W
R6817 301 259 7922 MT-GLAZE 5.1K JA 1/16W
R6818 301 264 6412 MT-GLAZE 220 FA 1/10W
R6819 301 264 6412 MT-GLAZE 220 FA 1/10W
R6821 301 264 6412 MT-GLAZE 220 FA 1/10W
R6822 301 264 6412 MT-GLAZE 220 FA 1/10W
R6823 301 264 6412 MT-GLAZE 220 FA 1/10W
R6824 301 256 3412 MT-GLAZE 7.5K JA 1/10W
R6826 301 224 9019 MT-GLAZE 10K JA 1/16W
R6828 301 255 7015 MT-GLAZE 51 JA 1/10W
R6829 301 265 0211 MT-GLAZE 390 FA 1/10W
R6831 301 224 9019 MT-GLAZE 10K JA 1/16W
R6832 301 259 7922 MT-GLAZE 5.1K JA 1/16W
R6833 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6834 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6836 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6837 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6838 301 224 9019 MT-GLAZE 10K JA 1/16W
R6839 301 224 9019 MT-GLAZE 10K JA 1/16W
R6841 301 224 9019 MT-GLAZE 10K JA 1/16W
R6842 301 224 9019 MT-GLAZE 10K JA 1/16W
R6870 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6875 301 225 8110 MT-GLAZE 10 JA 1/16W
R6880 301 225 8110 MT-GLAZE 10 JA 1/16W
R6884 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6886 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6887 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6888 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6889 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6891 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6892 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6893 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
RB6801 945 036 0986 R-NETWORK 47X4 1/32W
945 037 0831 R-NETWORK 47X4 1/16W
RB6802 945 036 0986 R-NETWORK 47X4 1/32W
945 037 0831 R-NETWORK 47X4 1/16W
DIODE
D6801 407 265 0418 LED SMLE12WBC7W1HR
D6802 407 265 0418 LED SMLE12WBC7W1HR
D6803 407 265 0418 LED SMLE12WBC7W1HR
D6804 407 265 0418 LED SMLE12WBC7W1HR
D6806 407 265 0418 LED SMLE12WBC7W1HR
D6807 407 265 0418 LED SMLE12WBC7W1HR

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
