Sartorius Cubis Series User Manual

Executing a Task: Checkweighing
D t If you haven’t already done so, go to Application Management.
y The task selection is displayed.
t Select the desired task.
or
t If the desired task is already marked, select Start.
Define check values by entry:
t Select the input field Setp and enter the target.
t Select the input field Min or Max and enter the minimum or maximum check
values.
or
Define check values with current load:
t Place the weight on the weighing pan.
t Select More.
t Select the field of the check value with the current weight value you want
to use.
t If required, repeat the process with additional weights for the other check
values.
t To exit the input mode without saving the value, select Back.
t To start checkweighing, select Start.
y The entered check values are displayed graphically.
t Place the object to be checked on the weighing pan.
Checkweighing
Cubis MSU User Manual 111

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
