Voltage Element
(Relay Word bits)
Operating
Voltage
Pickup Setting/Range See Figure
27S V
S
27SP
0.00 - 150.00 V secondary {150 V voltage inputs}
0.00 - 300.00 V secondary {300 V voltage inputs}
Figure 3.25
59S1 V
S
59S1P
0.00 - 150.00 V secondary {150 V voltage inputs}
0.00 - 300.00 V secondary {300 V voltage inputs}
59S2 V
S
59S2P
0.00 - 150.00 V secondary {150 V voltage inputs}
0.00 - 300.00 V secondary {300 V voltage inputs}
