Date Code 20001006 Front-Panel Interface 11-3
SEL-351 Instruction Manual
Figure 11.3: SEL-351 Relay Front-Panel Pushbuttons – Primary Functions (continued)
Secondary Functions
After a primary function is selected (see Figure 11.2 and Figure 11.3), the pushbuttons then
revert to operating on their secondary functions (see Figure 11.4).
Use the left/right arrows to underscore a desired function. Then press the SELECT pushbutton
to select the function.
