Date Code 20001006 Setting the Relay 9-33
SEL-351 Instruction Manual
Row Bit Definition
Primary
Application
43 TMB8A Channel A, transmit bit 8
(47) TMB7A Channel A, transmit bit 7
TMB6A Channel A, transmit bit 6
TMB5A Channel A, transmit bit 5
TMB4A Channel A, transmit bit 4
TMB3A Channel A, transmit bit 3
TMB2A Channel A, transmit bit 2
TMB1A Channel A, transmit bit 1
44 RMB8B Channel B, received bit 8
(48) RMB7B Channel B, received bit 7
RMB6B Channel B, received bit 6
RMB5B Channel B, received bit 5
RMB4B Channel B, received bit 4
RMB3B Channel B, received bit 3
RMB2B Channel B, received bit 2
RMB1B Channel B, received bit 1
45 TMB8B Channel B, transmit bit 8
(49) TMB7B Channel B, transmit bit 7
TMB6B Channel B, transmit bit 6
TMB5B Channel B, transmit bit 5
TMB4B Channel B, transmit bit 4
TMB3B Channel B, transmit bit 3
TMB2B Channel B, transmit bit 2
TMB1B Channel B, transmit bit 1
