Section 03 ENGINE
Sub-Section 08 (EXHAUST SYSTEM)
03-08-9
NOTE:
Due to exhaust cone angle, it may have to
be rotated to obtain alignment.
Push cone
no. 5
until it touches tuned pipe, then
tighten exhaust clamp
no. 22
and torque to 10
N•m (88 lbf•
in
).
NOTE:
Exhaust clamp nuts should be tightened
alternately to assure no leakage and to obtain
specified torque.
-
CAUTION
There must be no gap between tuned pipe
cone and tuned pipe head.
