Section 08 PROPULSION SYSTEM
Sub-Section 03 (DRIVE SYSTEM)
08-03-7
TYPICAL
1. PTO flywheel remover (P/N 295 000 001)
Using a suitable wrench or socket, unscrew PTO
flywheel COUNTERCLOCKWISE when facing it
and hold extension handle locking the magneto
flywheel.
TYPICAL
1. Extension handle locking crankshaft
NOTE:
When splines of PTO flywheel are worn
out and special tool can not be used, proceed with
the following alternate method.
Use a pipe wrench and install it on PTO flywheel
as illustrated.
TYPICAL
1. Extension handle locking crankshaft
SPX, GSX, GTX, XP and HX Models
PTO flywheel is loosen using PTO flywheel re-
mover (P/N 295 000 156).
Install special tool.
XP AND HX MODELS
1. PTO flywheel remover
F01D1AA
1
F01D49A
1
F01D4AA
1
F00B04A
F00I01A
1
