Section 12 TECHNICAL DATA
Sub-Section 03 (GSX MODEL)
12-03-2
ELECTRICAL GSX (5624)
Magneto generator output 180 W @ 6000 RPM
or 5.0 A @ 6000 RPM
Ignition system type Digital DC-CDI
Spark plug Make and type NGK BR8ES
Gap 0.5 - 0.6 mm (.020 - .024 in)
Ignition timing
(BTDC)
mm (in) 3.38 (.133)
Degrees 22° ± 1 @ 3500 RPM
Generating coil Not applicable
Battery charging coil
0.1 - 1
Ω
Trigger coil
190 - 300
Ω
Ignition coil
Primary
0.33 - 0.62
Ω
Secondary
8.4 - 15.6 k
Ω
Engine rev limiter setting 7200 (± 50) RPM
Battery (Yuasa/Exide) 12 V, 19 A•h
Fuse Starting system 5 A
Charging system 2 x 15 A
VTS system 7.5 A
ADDITIONAL INFORMATION:
CARBURETION GSX (5624)
Carburetor Type Mikuni BN-40I-38 (diaphragm)
Quantity 2
Main jet 142.5
Pilot jet 70
Spring 80 g
Adjustment Low-speed screw 1 turn ± 1/4
High-speed screw 0
Idle speed (in water) 1500 RPM
Idle speed (out of water) 3000 RPM
Fuel Type Regular unleaded gasoline
Minimum octane no. 87
Fuel return line orifice MAG and PTO: 0.8 mm (.031 in)
ADDITIONAL INFORMATION:
COOLING GSX (5624)
Type Open circuit – Direct flow from jet propulsion unit
Thermostat None
Monitoring beeper setting 86-94°C (187-201°F)
ADDITIONAL INFORMATION:
