Section 12 TECHNICAL DATA
Sub-Section 03 (GSX MODEL)
12-03-3
PROPULSION GSX (5624)
Propulsion system Bombardier Formula Pump
Jet pump type Axial flow single stage
Impeller rotation (seen from rear) Counterclockwise
Transmission Direct drive
Coupling type Crown splines
Oil type SEA-DOO JET PUMP SYNTHETIC
POLYOLESTER OIL 75W90 GL5
Steering nozzle pivoting angle 26°
Minimum required water level 90 cm (35 in)
Drive shaft deflection (maximum) 0.5 mm (.020 in)
Impeller outside diameter 139.5 mm (5.490 in)
Impeller/wear ring
clearance
New 0.0 - 0.4 mm (.000 - .016 in)
Wear limit 1.00 mm (.040 in)
Impeller shaft end play (new) 0.12 - 0.54 mm (.005 - .021 in)
Impeller shaft side play 0.05 mm (.002 in)
Impeller pitch/material Progressive pitch 16° - 23°/stainless steel
ADDITIONAL INFORMATION: Do not mix different brands or oil types.
DIMENSIONS GSX (5624)
Number of passenger (driver incl.) 2
Overall length 267 cm (105 in)
Overall width 116 cm (45.7 in)
Overall height 94 cm (37 in)
Dry weight 227 kg (500 lb)
Load limit (passenger and 10 kg (22 lb) luggage) 165 kg (364 lb)
ADDITIONAL INFORMATION:
CAPACITIES GSX (5624)
Fuel tank 56.5 L (15 U.S. gal)
Impeller shaft reservoir Capacity 70 mL (2.4 U.S. oz)
Oil level height Up to plug
Oil injection reservoir 6 L (1.6 U.S. gal)
ADDITIONAL INFORMATION:
