HF Series Generators
Configuration
CF-1018R3
14
4. Set the new value by pressing the corresponding “Increase”or
“Decrease” buttons. Value on “KV Tracking” (optional) assigns by default
one Formula for “Zero Point” operation mode to the selected RF
workstation. Set also the selected AEC Areas by default for each
Workstation in the system (optional).
5. Select the next workstations to be configured and set the respective
values of each one.
6. Exit from configuration mode by pressing the “Configuration” button, then
a double-bip will sound confirming the process.
7. Exposures made from workstations configured with:
G Device “Direct (No Bucky), Bucky -1, Bucky-2 and Standard Tomo”
are only enabled with the internal “Preparation” and “Exposure”
signals controlled by the Handswitch or Rad Footswitch.
G Device “Standard RF” and “DSI”areonly enabled with the
external signals for “Preparation”, “RAD Exposure” and “Fluoro
Exposure”. Fluoro can only be made from this Device
selection.
G Device “Infimed: DSI, Cine, DSA”areonly enabled with the
external “Digital Preparation” and “Exposure” signals connected
to Terminal Block 4TS3 of the Generator Cabinet.
1) Optional “Tomo / Bucky Adaptation Board” (in the Power
Cabinet) is required to configure more than two Buckys or one
Tomo Device in the system.
For system without the optional “Tomo / Bucky Adaptation Board”,
it can only work directly with two Buckys, and the value assigned
to them must be “1” and “2” in the second value.
2) TOMO must be always related to Bucky-1. Only one TOMO can
be used in the system, so only one of the workstations should be
configured with the value “3” in the second value.
3) Optional “AEC Control Board” (connected to the Console CPU
Board) is required to work with AEC.
Optional “AEC Adaptation Board” is required to configure any
no-standard or more than one Ion Chambers in the system.
Note .
