The 3 large tanks can be adjusted to provide product to either seed or fertilizer knives in a dual-shoot
configuration. If you would like to dispense product from a tank to the seed runs, connect the far-left run
to the far-left meter, and then work your way across, connecting meters to every second run. If you
would like to dispense product from a tank to the fertilizer runs, connect the far-right run to the far-right
meter, and work your way across, connecting meters to every second run.
NOTE: Ensure that the runs that are not connected have a plug firmly installed with an airtight
seal. Failure to create an airtight seal may cause an uneven seeding condition.
Always meter a small amount of product in a stationary position to ensure that each product is delivered
in the desired seed or fertilizer knives.
To change from seed to fertilizer or from fertilizer to seed, take all the yellow or black plugs out and
replace them with the corresponding meter’s flexible tube. Insert the yellow or black plugs where you
disconnected flexible tubes.
NOTE: The fan connected to the top of air splitter is the seed fan and the lower fan is
the fertilizer fan. The air splitter air gates are adjustable to safeguard against any
product “siphoning”.
WARNING: The product delivery lines can NOT be removed while the fans are running.
This will cause a large product loss at a rapid rate.
