SEEDMASTER 2023
49
5. Insert slide-gate and open meter bottom cover (approximately 1 gal. of product will fall out).
6. Inspect metering.
7. Close bottom meter cover (ensure a good seal) and remove slide-gate.
8. Reinstall slot cover, tightening wing nut while holding external wings in vertical position
NOTE: Poor quality fertilizer or other foreign materials may cause uneven metering or damage to
meter components. Screening of all products going into the Nova is highly recommended. The
slot cover requires a proper seal to ensure there is no air loss.
WORK LIGHTS
There are three work lights on a Nova cart. One is located at the walkway, another is located at the
signal light bracket, and one is installed at the conveyor. The switch for the work light is mounted on the
driver side of the Nova below the catwalk. NOTE: Monitor must be turned on for lights to operate.
WORK LIGHT SWITCH
Note: Protected by 10-amp fuse found on the main cable that plugs to the tractor at the front of the
machine.
