Sharp IV-S20 User Manual

9-5
Shared settings
9
Line type
Solid lines
Dotted lines
Image processing used
Window containing a
binary image
Binary image window
mask
Measurement programs
Distance and angle measurement (center of gravity), area
measurement by binary conversion, counting quantities by
binary conversion, identifying objects by binary conversion
Distance and angle measurement (center of gravity), area
measurement by binary conversion, counting quantities by
binary conversion, identifying objects by binary conversion
1. Specifying the center
2. Specifying the radius
· Up key · Down key · Left key · Right key
· Up key · Down key · Left key · Right key
Line type
Solid lines
Dotted lines
Image processing used
Window containing a
binary image
Binary image window
mask
Measurement programs
Distance and angle measurement (center of gravity), area
measurement by binary conversion, counting quantities by
binary conversion, identifying objects by binary conversion
Distance and angle measurement (center of gravity), area
measurement by binary conversion, counting quantities by
binary conversion, identifying objects by binary conversion
(3) Circle window
[How to set a circle window]
The following items on the settings menu can be used to define the circle window: center,
radius. Shown here is an example of how to define a solid line round window.
(4) Elliptical window
[How to set an elliptical window]
The following items on the settings menu can be used to define the elliptical window: center,
radius. Shown here is an example of how to define a solid line elliptical window.
· Up key
1. Specifying the center
2. Specifying the radius
· Down key
· Up/right key · Down/left key
· Left key · Right key
