9-23
Shared settings
9
Reference image
(model 0)
Detected coordinates
(model 0)
Search area
(model 0)
Reference image
(model 1)
Detected coordinates
(model 1)
Search area
(model 1)
· Reference image
· Target image
Detected coordinates
(model 0)
Detected coordinates
(model 1)
Position of reference image
θ
Detecting the amount of angular deviation
· Image that has been rotated around its center in step 1
[Example of angular correction]
1. Detection of the amount of angular deviation (using measurement 0, 2 point search
(positional deviation measurement).
2. Performing measurement 1 (of distance and angle measurement) on an image that has
been rotated around its center by the amount of angular diviation detected in step 1.
