9-42
Positional deviation measurement
9
· For more information on numerical calculations see section 9-2 [4] Numerical calculations.
Note: You must run a test using item 6 TEST A RUN, before making any calculations.
Continued from the previous page
Continued on the following page
[NUMERIC CALC]
(TYPE00-MEAS.0-POS-DEVIATION)
1CALC.RESULT
N00(0~15)
2OBJECT TYPE
NO COORD[X Y] DEVIAT[x y] MATCH [M]
ANGL-DEV[B] NUM-CALC[NC] CNST[C]
3FORMULA
REG.0(0~7) MDL0(0~1) N00(0~15)
+ - ∗
/ ←→ DEL END
4UPPER&LOWER LIMIT +
00000650.0~+00000700.0
5OUTPUT
NO Y0(0~7) C000(0~107)
6TEST A RUN
(SET KEY)
7UPPER MENU
N00
N01
N02
N03
[X]
[M]
0X0
＋
0X1 Y0
+00000650.0~+00000700.0 +00000660.0 OK
N00
＊
0M1 Y1
+00065000.0~+00070000.0 +00064000.0 NG
Return to the [TYPE00-MEAS0] menu and select item 7 OUTPUT CONDITIONS (output condition).
The numbers ranging from 0 to 7 in front of the characters are registration numbers.
· The number of formulas which can be set are dictated by the selections made in items 2 and 3
as follows.
Numerical calculation
1CALC.RESULT
(calculation result)
2OBJECT TYPE (type)
3FORMULA
4UPPER&LOWER LIMIT
5OUTPUT
6TEST A RUN
(make a test run)
7UPPER MENU
Setting details
Set the recording and display of the results from arithmetical operation for
specified output data at any value from 00 to 15.
Select the type of data being calculated.
A number of formula settings are used.
The first line will change according to the selection made in item 2.
Note: Please use a smaller number for the number of formulas at N (00 to 15)
than that used for 1 CALC. RESULT N (00 to 15).
Set the upper and lower limits for decisions.
Set the output conditions for the results of calculations.
Pressing the SET key will record the setting details as well as run a test.
Returns you to the [TYPE00-MEAS0] menu.
2OBJECT TYPE
Coordinates X/Y
Coordinate deviation x/y
Degree of match M
Angular deviation B
Numerical calculation NC
Constant C
Model 0
0X0 to 7X0/0Y0 to 7Y0
0x0 to 7x0/0y0 to 7y0
0M0 to 7M0
0B to 7B
ABS//TAN/ATAN (00 to 15)
-99999999.9 to +99999999.9
Model 1
0X1 to 7X1/0Y1 to 7Y1
0x1 to 7x1/0y1 to 7y1
0M0 to 7M0
Selection of 2
The coordinates [XY], the deviation
coordinates [xy], and the degree of
match with the reference image. [M]
Angular deviation [B]
Numerical calculations [NC]
Constant [C]
The first line of the display
Record 0 (0 to 7) Model (0 to 1)
N00 (0 to 15)
Record 0 (0 to 7) N00 (0 to 15)
ABS TAN ATAN N00 (0 to 15) (the
second line will not be displayed)
+00000000.0 (the second line will not
be displayed)
