Lead inspection
9
Continued from the previous page
Continued on the following page
Return to the [TYPE00-MEAS1 to 3] and select item 9 OUTPUT CONDITIONS
[NUMERIC CALC] (TYPE00-MEAS.1-INSPECT LEAD)
1CALC. RESULT N00(0~15)
2OBJECT TYPE NO MATCH[M] CORD[X Y] QTY[K]
MAX.DIST[MXD] MIN.DIST[MND]
MAX-L.LENG[MXL] MIN-L.LENG[MNL]
NUM-CALC[NC] CNST[C]
3FORMULA REG.0(0~3) MES-OBJ.0(0~7) N00(0~15)
+ - ∗
/
←→ DEL. END
4UPPER&LOWER LIMIT
+
00000000.0~ +00000000.0
5OUTPUT NO Y0(0~7) C000(0~107)
6RUN A TEST (SET KEY)
7UPPER MENU
N00
N01
N02
N03
[MXD]
0MXD0
Y0
+00000050.0~ +00000052.0 +00000051.0 OK
· The number of formulas which can be set are dictated by the selections made in items 2 and 3 as follows.
The numbers ranging from 0 to 3 in front of the characters are registration numbers. The numbers
ranging from 0 to 7 after the characters are numbers for the object to be measured.
· For more information on numerical calculations see section 9-2 [4] Numerical calculations.
Note: You must run a test using item 6RUNATEST before making any calculations.
Numerical calculation
1CALC.RESULT
(calculation result)
2OBJECT TYPE
3FORMULA
4UPPER&LOWER.LIMIT
5OUTPUT
6RUNATEST
(make a test run)
7UPPER MENU
Setting details
Set the recording and display the results from arithmetical operation for
specified output data at any value from 00 to 15.
Select the type of data being calculated.
A number of formula settings are used.
The first line will change according to the selection made in item 2.
Note: Please use a smaller number for the number of formulas at N (00 to 15)
than that used for 1 CALC. RESULT N (00 to 15).
Set the upper and lower limits for decisions.
Set the output conditions for the results of calculations.
Pressing the SET key will record the settings details as well as run a test.
Returns you to the [TYPE00-MEAS1 to 3] menu.
2FORMULA
Degree of match [M]/ Coordinates [X]/[Y]
Number of objects [K]/maximum distance
[MXD]/minimum distance [MND]
Maximum lead length [MXL]/minimum lead length [MNL]
Numerical calculation [NC]
Constant [C]
Number of formulas
0M to 3M/0X to 3X/0Y to 3Y
0K0 to 3K7/0MXD0 to 3MXD7/
0MND0 to 3MND7
0MXL0~3MXL7/0MNL0~3MNL7
ABS//TAN/ATAN (00 to 15)
-99999999.9 to +99999999.9
Selection of 2
The degree of match with the
reference image [M] coordinates [XY]
Number of objects [K], maximum
distance [MXD], minimum distance
[MND], maximum lead length [MXL]
and minimum lead length [MNL]
Numerical calculations [NC]
Constant [C]
The first line of the display
Record 0 (0 to 3) N0 (0 to 15)
Record 0 (0 to 3) Object to be
measured 0 (0 to 7) N0 (0 to 15)
ABS TAN ATAN N00 (0 to 15)
(the second line will not be displayed)
+00000000.0 (the second line will not
be displayed)
