9-96
Counting quantities by binary convension
9
· If item 1 PAGE NO. (registration number) is set to YES, then items 2 to 5 will be displayed.
· The input signals which may be set depend on the selection made in item 3 as follows.
The numbers ranging from 0 to 3 in front of the characters are registration numbers.
· For more information on output conditions, see the “PC Function,” in Chapter 10.
Continued from the previous page
Return to the MAIN OPS MENU
DEL.
[OUTPUT CONDITIONS]
(TYPE00-MEAS.1-CNT-BIN-OBJ)
1PAGE NO. 0(0~4) REG.NO YES
2SET POSITION MOVE
3INPUT SIGNAL REGT.NO.0(0~3)
T-ARA A QTY K
CAL N00(0~15) AUXRLY C000(0~127)
4LOGICAL SYMBOL
5OUTPUT SIGNAL
AUX.RLYC000(0~127) DEL.
6UPPER MENU
[PAGE0]
INPUT0
LOGIC
INPUT1
LOGIC
INPUT2
LOGIC
INPUT3
LOGIC
10 234567OUT
Continued on the following page
Selection of 3
Total area A
Number of objects K
Calculation N
Secondary relay C
Input signals
0A to 3A
0K to 3K
N00 to N15
C000 to C127
To Next Page
