9-111
9
Existence inspection by point measurement
Evaluation conditions Setting details
1 CHG PAGE
(page change)
2 P
·
·
9 P
0 MAKE A TEST RUN
q UPPER MENU
Pressing the SET key will test the evaluation conditions, display the
test results.
This will return you to the [TYPE00-MEAS1 to 3] menu.
The white or black judgment condition assigned to point numbers 0
to 255 is set using the up and down keys.
· The numbers of the selected points will flash.
· No color is displayed for unregistered point numbers.
Point numbers 2 to 9 can be displayed as groups of 8 objects,
using the up and down keys.Pressing the SET key will test the
evaluation conditions, display the test results.
OK/NG judgment
White: Will be OK if a majority of the objects to
be measured is seen as white.
Black: Will be OK if a majority of the objects to
be measured is seen as black.
Example: When the object to be measured is
an 8 x 8 area (64 pixels) and white
was selected for an OK judgement,
if the amount of white in the area is
33 pixels or more, a judgment of OK
will be produced.
Not displayed for point numbers which
have not been previously registered on
the point setting menu.
These displays can be set using the up
and down keys.
(The choices are NO, Y0 to 7, C000 to
C127)
Continued from the previous page (when BIN-CONV (binary conversion) was selected for the processing mode)
Go to page 9·113
[EVALUATION COND] (TYPE00-MEAS.1-POINT-MEAS)
1
CHG PAGE TEST RUN [
TEST RESULT]
[OUT]
2
P000 : WH OK NO
3
P001 : WH OK NO
4
P002 : WH OK NO
5
P003 : WH OK NO
6
P004 : WH OK NO
7
P005 :
8
P006 :
9
P007 :
0
MAKE A TEST RUN (SET KEY)
q
UPPER MENU
Return to the [TYPE00-MEAS1 to 3] menu, and select item 9 OUTPUT CONDITIONS.
· Assign an OK measurement value of white or black after checking the test results (OK/NG)
from the item 0 MAKE A TEST RUN.
To Next Page
