9-112
9
Existence inspection by point measurement
Evaluation condition Setting details
1 CHG PAGE
(page change)
2 P
-
-
9 P
q MAKE A
TEST RUN
w UPPER MENU This will return you to the [TYPE00-MEAS1 to 3] menu.
Set the range of the average light level for all point numbers from 0 to
127.
- The numbers of the selected point will flash.
- No light level is displayed for unregistered point numbers.
Point numbers 2 to 9 can be displayed as groups of 8 objects, using
the up and down keys. Pressing the SET key will test the evaluation
conditions, display the test. results.
0 STORE ALL
COND
The light level is collectively averaged for all of the point numbers that
have been registered.
These displays can be set using the up
and down keys. (The choices are NO,
Y0 to 7, or C000 to C127.)
From page 9-110: When AV-LIGHT-LEVEL (average light level) is selected for the processing mode.
Return to the [TYPE00-MEAS1 to 3] menu, and select item 9 OUTPUT CONDITIONS.
[EVALUATION COND] (TYPE00-MEAS.1-POINT-MEAS)
1
CHG PAGE TEST RUN
[
TEST RESULT]
[OUT]
2
P000 : 000~255 100 OK NO
3
P001 : 000~255 100 OK NO
4
P002 : 000~255 100 OK NO
5
P003 : 000~255 100 OK NO
6
P004 : 000~255 100 OK NO
7
P005 :
8
P006 :
9
P007 :
0
STOREALLCOND
000~255
q
MAKE A TEST RUN
(SET KEY)
w
UPPER MENU
Average light level of the points
Continued on the following page
- Set the measurement value (range of the average light level) that will produce a result of OK
in item q MAKE A TEST RUN.
OK/NG judgment
Æ OK when the average light level of a
point is within the range set. NG when
it is outside the range.
Not displayed for point numbers which
have not been previously registered on
the point setting menu.
Pressing the SET key will test the evaluation conditions, display the test
results.
To Next Page
