9-114
9
Existence inspection by point measurement
MSR-CHNG REG-CHNG PC-MONTR SET-SCRN MANL-TYP-CHG
X0~6
:
Y0~7
:
BUSY
:
F H C1ALLC2NO
VX.X
(TYPE00)
OK
MEAS. XXXXXXms
MEAS1 CAM1 POINT MEAS
P000:116 OK
P001:120 OK
P002:114 OK
P003:118 OK
P004:116
P005:115
P006:
P007:
[Display of the measured results]
MSR-CHNG REG-CHNG PC-MONTR SET-SCRN MANL-TYP-CHG
X0~6
:
Y0~7
:
BUSY
:
F H C1ALLC2NO
VX.X
(TYPE00)
OK
MEAS. XXXXXXms
MEAS1 CAM1 POINT MEAS
P000:○ OK P001:○ OK
P002:○ OK P003:○ OK
P004:○ OK P005:○ OK
P006: P007:
P008: P009:
P010: P011:
P012: P013:
P014: P015:
Final evaluation result
Measuring time
Evaluation of the correct black or white
color detected at registered points
[Display of the measured results]
Form the preceding page
Object to
be measured
White (display ○)
Black (display ●)
OK
NG
NG
OK
White Black
Evaluation condi-
tion (OK)
· The following is an example of how the results are displayed when AV-LIGHT-LEVEL
(average light level) is selected for the processing mode.
Average light level of registered points
and the OK/NG evaluation of each
· When the cursor is moved to the REG-CHNG (change register) item and the up or down key is
pressed, the point number display will show groups of 16 objects at a time.
Up key: Next set of numbers, Down key: Previous set of numbers
When the TRG/BRT key is pressed, manual measurement will start, and the points will be measured.
The following is how the display of the results will look when BIN (binary) was selected for the
processeing mode.
To Next Page
