Sharp IV-S20 User Manual

13-10
Communication
13
(2) Measurement data reading function 2 (measurement numerical data): code 22
(H)
The data last output and block data from a specified measurement function are output.
- Measurement _ Number of the measurement whose numerical data will be output: 0 to 3
- Block _ Specified block from which the data from a specified measurement function will be
output
- Object type _ Object type for which the measurement was executed: 00 to 15
- Output evaluation result (Y0 to Y15) _ 0: NG or unspecified, 1: OK
- Specified block data _ Numerical data in a specified block (up to 512 bytes)
(3) Measurement data reading function 3 (evaluation result + logical result and calculation
result): code 23
(H)
The most recent final evaluation result, and the logical result and final calculation result of each
measurement are read.
- Measurement _ Number of the measurement whose numerical data will be output: 0 to 3
- Object type _ Object type for which the measurement was executed: 00 to 15
- Output evaluation result (Y0 to Y15) _ 0: NG or unspecified, 1: OK
- 2 _ Logical result, calculation evaluation, calculation result
These data are output in the order of the measurement function numbers: 0 to 3.
(4) Illuminance level reading: code 28
(H)
The illuminance level measured by the illuminance monitor function and the evaluation result are
read.
- Camera No. _ 1: camera 1, 2: camera 2
- Object type _ Object type for which the measurement was executed: 00 to 15
- Result _ 0: NG, 1: OK
- Illuminance _ 0 to 255.0
:22
:22
SC
(H)
SC
(L)
RC
(H)
RC
(L)
CR
Y15
Specified
block data
Y1Y0
Measure-
ment
Ë Response
Output evaluation
result
…
SC
(H)
SC
(L)
Ë Command
CR
Object
type
Block
Ë Response
:28 RC
(H)
RC
(L)
Illuminance
10
2
10
1
10
0
10
-1
SC
(H)
SC
(L)
CR
Result
Camera No.
:28 SC
(H)
SC
(L)
Ë Command
CR
Object
type
Ë Response
:
:
2
23
3
Output evaluation
result
RC
(H)
RC
(L)
Y15 Y1 …Y0
SC
(H)
SC
(L)
CR
Data on
measure-
ment 1 2
Data on
measure-
ment 2 2
Data on
measure-
ment 3 2
1
Ë Command
Object
type
Object
type
SC
(H)
SC
(L)
CR
Measure-
ment 0
Measurement 0
Measure- ment 1 Measure- ment 2 Measure- ment 3
Camera 1 Camera 2
Camera 1
data 2
Camera 2
data 2
