Sharp IV-S20 User Manual

3-16
3
Operation Examples (Degree of match inspection)
1
FC1H
[OBJECT TYPE COND]
1OBJECT TYPE NO. 00(0~15)
2EDIT COPY(←OBJTYPE00) INITIALIZE
3TITLE REGISTRATION (TO NEXT SUB-MENU)
4MEAS.0, CAMERA1 NO (TO NEXT SUB-MENU)
5POS. ADJ.CAMERA1 NO ADJ. [ REG. 0-1PNTSXY］
6MEAS.0, CAMERA2 NO (TO NEXT SUB-MENU)
7POS. ADJ.CAMERA2 NO ADJ. [ REG. 0-1PNTSXY］
8SELECT CAMERA IMG NO CAM1 CAM1 CAM1&2
0MEASUREMENT 1 NO (TO NEXT SUB-MENU)
qMEASUREMENT 2 NO (TO NEXT SUB-MENU)
wMEASUREMENT 3 NO (TO NEXT SUB-MENU)
eFINAL CALC RESULT (TO NEXT SUB-MENU)
rFINAL OUTPUT COND (TO NEXT SUB-MENU)
tSYSTEM-IN/OUT (TO NEXT SUB-MENU)
yHALT MEAS ON NG NO YES
uUPPE
R MENU
1
3
2
［TYPE00-MEAS1］
1MEAS SELECTION NO CHECK-DEG-OF-MATCH 
DST&AGL MES . ( GRAY&EDGE GRAV)
INSPECT-LEAD MEASR-BIN-AREA
CNT-BIN-OBJ LABEL-BIN-OBJ
POINT MEAS

3SELECT CAMERA CAM1 CAM2
4COPY EXEC←TYPE00 − MEAS1 − NO
5INITIALIZATION EXEC
6MEAS.PROG. COND (TO NEXT SUB-MENU)
7EVALUATION COND (TO NEXT SUB-MENU)
8NUMERIC CALC COND (TO NEXT SUB-MENU)
9OUTPUT CONDITIONS (TO NEXT SUB-MENU)
0UPPER MENU
Continued from the preceding page
(3) Operation on the [OBJECT TYPE COND] (conditions of object type) menu
1. Move the cursor to 0 MEASUREMENT 1 and press the SET key.
- The [TYPE00-MEAS1] (type: 00, measurement: 1) menu will be displayed.
(4) Operation on the [TYPE00-MEAS1] menu
1. Move the cursor to 1 MEAS SELECTION (selection of measurement) and press the SET
key.
2. Move the cursor to CHECK-DEG-OF-MATCH (degree of match inspection) and press the
SET key.
3. Move the cursor to 6 MEAS.PROG. COND (conditions of measurement program) and press
the SET key.
- The [MEASURING COND] (measurement condition) menu will be displayed.
Continued on the following page
