3-17
3
Operation Examples (Degree of match inspection)
Continued from the preceding page
(5) Operation on the [MEASURING COND] (measurement condition) menu
1. Move the cursor to 1 REGST NO. (register number) and press the SET key. Move the
cursor to YES and press the SET key.
- Items 2 to 5 will be displayed.
2. Move the cursor to 3 MODEL 0 POSITION (model 0, positioning) and press the SET key.
Move the cursor to SEARCH and press the SET key.
3. Move the cursor to 5 EVALUATE CRITERIA (criteria condition) and press the SET key.
- The gray scale search matching setting menu, image window, and search window will be
displayed.
(6) Image adjustment
1. Press the SEL key.
- The image taken by camera 1 will be displayed.
- If the image is so bright that the menu is hard to see, press the TRG/BRT key to reduce
the brightness of the image. Then, the brightness indicator in the upper right corner of
the screen will change from H to L.
2. Adjust the focus and aperture (iris) of the camera lens (see page 5-1), so that the object to be
measured is clear and easily distinguished.
3. Press the SEL key to enter the freeze image mode.
- The indicator in the upper right corner of the screen will change from T (through) to F
(freeze).
- To store an image for the following gray scale search matching setting operations, the
screen must be in the freeze image mode. (See section 7-2 "Screen specifications" for
details about the through/freeze mode.)
Continued on the following page
1
2
3
1
2
[
MEASURING COND
]
(TYPE00-MEAS1-DEG OF MATCH)
1REGST NO. 00(0~15) REG.NO YES
2MODE
GRAY-IMG-PROC BINARY-IMG-PROC
3MODEL 0 POSITION
NO-SEARCH SEARCH
4MODEL 1 MEAS.OBJ NO YES(NO-SEARCH) YES(SEARCH)
5EVALUATE CRITERIA
(TO NEXT SUB-MENU)
6UPPER MENU
To Next Page
