Shihlin electric SDE-100A2 User Manual

170
S_LOW=0: It indicates that the speed unit is 0.1 rpm.
S_LOW=1: It indicates that the speed unit is 0.01 rpm.
S_LOW=2: It indicates that the speed unit is 1 rpm.
AUTO=1: When the current PR is done, the next PR would be executed automatically.
Data setting:
Data
Pulse: 0~1048575
Home return : This is composed of PE01 and PE02.
Bit
31~28
27~24
23~20
19~16
15~12
11~8
7~4
3~0
PE01
BOOT
X
DLY
X
Acc. / Dec.
PATH
PE02
ORG_DEF: 32bit
OPT setting:
OPT
Bit 7~4
Bit 3~0
Explanation
0
0
After home return, then the servo motor stops.
0
1
After home return, then the servo motor starts to run PATH#01.
0
2
After home return, then the servo motor starts to run PATH#02.
0
3
After home return, then the servo motor starts to run PATH#03.
~
~
~
3
D
After home return, then the servo motor starts to run PATH#61.
3
E
After home return, then the servo motor starts to run PATH#62.
3
F
After home return, then the servo motor starts to run PATH#63.
Parameter
