Shihlin electric SDE-100A2 User Manual

22
Speed option 1
SP1
0x06
＜Speed control mode＞
Used to select the speed command. When using SP3, make it
usable by making the setting of PD02~PD09.
Setting of
PD02~PD09
(Note)Input
signals
Speed command
SP3
SP2
SP1
When speed
option (SP3) is
not used.
(initial status)
0
0
Speed analog command (VC)
0
1
Inner speed command 1 (PC05)
1
0
Inner speed command 2 (PC06)
1
1
Inner speed command 3 (PC07)
When speed
option (SP3) is
made valid.
0
0
0
Speed analog command (VC)
0
0
1
Inner speed command 1 (PC05)
0
1
0
Inner speed command 2 (PC06)
0
1
1
Inner speed command 3 (PC07)
1
0
0
Inner speed command 4 (PC08)
1
0
1
Inner speed command 5 (PC09)
1
1
0
Inner speed command 6 (PC10)
1
1
1
Inner speed command 7 (PC11)
Note. 0：off (with SG)
1：on (with SG)
＜Torque control mode＞
Used to select the limit speed for operation. When using SP3,
make it usable by making the setting of PD02~PD09.
Setting of
PD02~PD09
(Note)Input
signals
Speed command
SP3
SP2
SP1
When speed
option (SP3) is
not used.
(initial status)
0
0
Speed analog command (VC)
0
1
Inner speed command 1 (PC05)
1
0
Inner speed command 2 (PC06)
1
1
Inner speed command 3 (PC07)
When speed
option (SP3) is
made valid.
0
0
0
Speed analog command (VC)
0
0
1
Inner speed command 1 (PC05)
0
1
0
Inner speed command 2 (PC06)
0
1
1
Inner speed command 3 (PC07)
1
0
0
Inner speed command 4 (PC08)
1
0
1
Inner speed command 5 (PC09)
1
1
0
Inner speed command 6 (PC10)
1
1
1
Inner speed command 7 (PC11)
Note. 0：off (with SG)
1：on (with SG)
S,T
Speed option 2
SP2
0x07
Speed option 3
SP3
0x08
Forward rotation
activated
ST1
0x09
Used to start the servo motor in the following directions:
(Note)Input signals
Servo motor starting direction
ST2
ST1
0
0
Stop(servo lock)
0
1
CCW
1
0
CW
1
1
Stop(servo lock)
Note. 0：off (with SG)
1：on (with SG)
If both ST1 and ST2 are switched on or off during operation, the
servo will be decelerated to a stop according to the value of
PC18, and the motor will be locked. The activation of analog
speed commands (VC) at 0V will not servo lock.
S
Reverse rotation
activated
ST2
0x0A
