Shihlin electric SDE-100A2 User Manual

31
(3). DO interface
Lamp, relay or photo coupler could be driven. A diode for relay load, or a suppressing resistor for lamp
load is necessary. (Permissible current: 40mA or less, inrush current: 100mA or less)
DO of sink mode
With the inner power supply
With the external power supply
DO of source mode
With the inner power supply
With the external power supply
