OPERATING INSTRUCTIONS | Bulkscan LMS511 8014829/ZNC5/2017-06-06 | SICK
Subject to change without notice
24
CONFIGURABLE FUNCTIONS
How to congure the calculation of the distance from the conveyor belt edges:
 On the Operating modecongurationbar,clickMaintenance to switch to mainte-
nance mode.
 Switch to the Edge monitoring tab. Set the limits of the monitored area (left eld
ends at and right eld ends at) so that the entire monitoring area can still be co-
vered.
Or:
Switch to the Monitor tab. Click and drag the outside left or right edge beam to the
required aperture angle
 Conguretheupperandlowermonitoringlimitsfortheleftandrightbeltedges(Up-
per limit and Lower limit) in the Edge detection tab.
 ConguretheAveraging lter Distance to edge, if required.
How to congure the signaling of belt edge warnings :
 Switch to the Edge monitoring tab.
 ConguretheDistance from the left edge and the Distance from the right edge from
which a warning is issued.
 Switch to the Interfaces tab.
 Click on Digital outputs to open the Digital outputs tab (see "4.13 Digital outputs“
on page 25).
 Select the assignment Information/Warnings for the required output.
 Select the required Logic.
 Select the required Warning (All, Conveyor edge left or Conveyor edge right).
 ConguretheSwitching delay, if required.
4.11 Averaging lter
The Bulkscan smooths the measured values for the calculation of the Flow, Center of
gravity, Bulk height, Belt speed and Distance to edgeusinganaveraginglteroverthe
previous n seconds.
The FlowaveraginglteraffectsboththeresultsfortheVolume ow rate and the Mass
ow rate.Youcanconguretheperiodfortheaveraging.
• Settherequiredaveraginglterto0secondstodisablethelter.
• Measurement tab, Averaging lter group, Flow, Center of gravity, Bulk height, Belt
speed or Distance to edge option.
4.12 Digital inputs
The Bulkscan has two digital inputs which are used to signal the belt operation and
reset the volume sum and mass sum.
How to congure the signaling of the belt operation:
 Switch to the Measurement tab.
 ConguretheBelt speed as Fixed value (see "4.1 Setting the belt speed“ on page
16).
 Check the Use status signal checkbox.
 ConguretheLogic for the digital input signal.
Alternatively,youcanalsomakethecongurationsettingsintheDigital inputs tab
How to congure the resetting of volume sum and mass sum:
 Switch to the Interfaces tab.
 Click on Digital inputs to open the Digital inputs tab.
 ConguretheSwitching condition of the digital input signal.
Note
Note
