13.1.9 Edge monitoring
Variable name Description Variable type Value range Unit
parBulkEdgeThreshold
Bulk edge detection
threshold
oat_32 20 … 10.000 mm
mvBulkEdgeDistance-
Left
Measured distance to left
bulk edge
oat_32
mvBulkEdgeDistance-
Right
Measured distance to right
bulk edge
oat_32
parBulkEdgeDist2Warn-
Left
Distance to left bulk edge
warning
oat_32 0 … 12.500 mm
parBulkEdgeDist2Warn-
Right
Distance to right bulk edge
warning
oat_32 0 … 12.500 mm
BsBulkEdgeWar-
ningLeft
Left bulk edge warning bool_1 0: Deactivated
1: Active
BsBulkEdgeWarning-
Right
Right bulk edge warning bool_1 0: Deactivated
1: Active
parConveyorUpperLi-
mitLeft
Conveyor belt edge left:
Upper left
oat_32 20 … 1.000 mm
parConveyorLowerLi-
mitLeft
Conveyor belt edge left:
Lower limit
oat_32 20 … 1.000 mm
parConveyorUpperLi-
mitRight
Conveyor belt edge right:
Upper limit
oat_32 20 … 1.000 mm
parConveyorLowerLi-
mitRight
Conveyor belt edge right:
Lower limit
oat_32 20 … 1.000 mm
mvConveyorDistance-
Left
Measured distance to left
conveyor belt edge
oat_32
mvConveyorDistance-
Right
Measured distance to right
conveyor belt edge
oat_32
parConveyorDist2Warn-
Left
Distance to left conveyor
belt edge warning
oat_32 0 … 12.500 mm
mvConveyorDistance-
Right
Measured distance to right
conveyor belt edge
oat_32 0 … 12.500 mm
BsConveyorWar-
ningLeft
Left conveyor belt edge
warning
bool_1 0: Deactivated
1: Active
BsConveyorWarning-
Right
Right conveyor belt edge
warning
bool_1 0: Deactivated
1: Active
parAveragingEdgeDi-
stance
Averaginglter(bulkedge
and conveyor belt edge)
13.1.10 Digital inputs
Permissible commands: sRN, sWN
Variable name Description Variable
type
Value range Unit
parUseBeltMoving
Use status signal for
the belt operation
bool_1 0: Deactivated
1: Active
DI1Logic
Logic of the status
signal for the belt
operation
uint_8 0: Active high
1: Active low
DI2Logic
Switching condition:
Reset volume sum
and mass sum
uint_8 0: Rising edge
1: Falling edge
