APPENDIX
Variable name Description Variable
type
Value range Unit
parLevelCompensation
Level for raising or
lowering the conveyor
belt level
int_8 –100 to 100 mm
Permissible commands: sMN
Method name Description
BsMeasure
Start the Measuring mode
BsMaintenance
Start the Maintenance mode
BsTeach
Start the teach-in process
BsLevelCompensation
Apply level compensation
13.1.6 Measured values
Permissible commands: sRN, sEN
Variable name Description Variable
type
Value range Unit
mvVolumeFlow
Volumeowrate oat_32 m³/h
mvMassFlow
Massowrate oat_32 t/h
mvVolumeSum
Volume sum oat_32 m³
mvMassSum
Mass sum oat_32 t
mvGravity
Center of gravity oat_32 0 to 1
mvHeight
Bulk height oat_32 m
mvDensity
Bulk density oat_32 t/m³
mvSpeed
Belt speed oat_32 m/s
Permissible commands: sMN
Method name Description
BsClearTotals
Reset measured values (volume sum, mass sum)
13.1.7 Measurement
Permissible commands: sRN, sWN
Variable name Description Variable
type
Value range Unit
parSpeedSource
Belt speed: Source uint_8 0: Fixed value
1: Encoder
2: Analog value
parFixedSpeed
Beltspeed(xedvalue) oat_32 –30 to +30 m/s
parUseBeltMoving
Use status signal for the
belt operation
bool_1 0: Deactivated
1: Active
DI1Logic
Logic of the status signal
for the belt operation
uint_8 0: Active high
1: Active low
LICencres
Encoder: Resolution oat_32 0.001 to 2000 mm/Inc
