Page #83 background imageLoading...
Page #83 background image
OPERATING INSTRUCTIONS| Bulkscan LMS5118014829/ZNC5/2017-06-06| SICK
Subject to change without notice
83
APPENDIX
13.1.3 Saving the conguration in the non-volatile memory
Followingsuccessfulconguration,youshouldsavetheparametersinthenon-volatile
memory.
Permissible commands: sMN
Method name Description
mEEwriteall
Savethecongurationinnon-volatilememory
13.1.4 Device information
Permissible commands: sRN, sEN
Variable name Description Variable type Value range
BsRefAvailable
Reference contour
available
bool_1 0: No
1: Yes
BsTeachFailed
Teach-in failed bool_1 0: No
1: Yes
BsTeachReady
Teach-in successful bool_1 0: No
1: Yes
BsInvalidPoints
Too many invalid
measuring points
within a scan
bool_1 0: No
1: Yes
BsContamination
Contamination of the
front screen
bool_1 0: No
1: Yes
13.1.5 Operating mode/Teach-in
Permissible commands: sRN, sEN
Variable name Description Variable type Value range Unit
BsState
Operating mode uint_8 1: Teach-in
2: Measuring mode
3: Maintenance
contourRef
Reference contour 381xoat_32 500 to 20,000 mm
contourMeas
Surface contour of
measured object
381xoat_32 15 to 25,000 mm
Permissible commands: sRN, sWN
Variable name Description Variable
type
Value range Unit
parAngleLeft
Angle left oat_32 –95 to 0 Degree
parAngleRight
Angle right oat_32 0 to 95 Degree
parTeachDistanceMax
Maximum distance
between sensor and
conveyor belt
oat_32 500 to 20,000 mm
parTeachCycles
Number of cycles for
averaging the refer-
ence contour
uint_32 100 to 10,000 Cycles
parTeachOutdoor
Optimization for for
slits or gaps
bool_1 0: Deactivated
1: Active
