TECHNICAL DATA
11 Technical data
11.1 Bulkscan LMS511 data sheet
Minimum Typical Maximum
Features
Infrared laser light source 895 nm 905 nm 915 nm
Laser protection class 1 (safe for eye) according to EN/IEC 60825-
1:2014 (complies with 21 CFR 1040.10 and
1040.11 except for deviations pursuant to Laser
Notice No. 50, June 2007)
Aperture angle 190°
Angular resolution 0,5°
Scan frequency 35 Hz 50 Hz 75 Hz
Bandwidth No limit
Heating yes
Operating range
Distance sensor - bulk material 0.5 m 20 m
Belt speed –30 m/s +30 m/s
Number of echoes evaluated 5
Performance
Power-up delay (temperature-dependent) 30 s 60 s
Cycle time 13,3 ms 20,0 ms 28,6 ms
Averaging lter 0 s 3.600 s
Measurement accuracy ±5 % ±3 %
Interfaces
Serial auxiliary interface/USB
Protocol
Data transmission rate
USB
57.600 Baud
Serial Host Interface
Protocol
Data transmission rate
RS 232/RS 422
57.600 Baud
Ethernet
Protocol
Data transmission rate
TCP/IP
10 Mbit/s 100 Mbit/s
Digital inputs 2
Encoder inputs 2
Digital outputs 6
Analog In-/ output: 5 diagnostic LEDs and one 7-segment display.
See accessories analog module BAM100 (see
"12.2 Accessories“ on page 77).
Electrical date
Electrical connection Device socket M12×5
