OPERATING INSTRUCTIONS | Bulkscan LMS511 8014829/ZNC5/2017-06-06 | SICK
Subject to change without notice
38
ELECTRICAL INSTALLATION
6.1.2 Suitable power supply
Risk of electrical shock!
The output circuit of the power supply must be safely electrically isolated from the input
circuit. This feature is normally provided by a safety transformer in accordance with IEC
742 (VDE 0551).
 Use a safety transformer to generate the supply voltage.
For information on the supply voltage for the Bulkscan and the heating (see "11 Techni-
cal data“ on page 68).
6.1.3 Cable lengths and wire cross-sections
 Observe the following maximum cable lengths and the related necessary wire
cross-sections.
Connection Maximum ca-
blelength
Minimum wire
cross-section
Notes
Supply voltage 0.25 mm² Power supply unit in
immediate vicinity
20m (with SICK
standard cables)
1.0 mm²
I/O 0.25 mm²
50 m 0.5 mm²
Data (RS-232) 2 m 0.25 mm²
(Twisted Pair screened)
Max. 115,200 baud
3 m
Max. 57,600 baud
10 m
Max. 19,299 baud
Data (RS-422) 500 m 0.25 mm²
(Twisted Pair geschirmt)
Max. 115.200 Baud
1.200 m Max. 38.400 Baud
Tab. 4: Maximum cable lengths and necessary wire cross-sections
 Lay the data cable separately from the power supply and motor cables, e.g., in sepa-
rate cable channels, to prevent interference.
6.2 Carrying out the electrical installation on the Bulkscan
Risk of tripping due to cables! Risk of damage to the cables!
Exposedcablesontheoorinareasusedbypeoplecanposearisk.
 Lay all cables so that there is no risk of tripping and all cables are protected against
damage.
Risk of reduced enclosure rating!
 Only connect and mount, if necessary, the electrical connections in a dry and clean
environment.
 Only use round connectors that are compliant with enclosure rating IP 67.
Note
