OPERATING INSTRUCTIONS | Bulkscan LMS511 8014829/ZNC5/2017-06-06 | SICK
Subject to change without notice
70
TECHNICAL DATA
Storage temperature range –40 °C +70 °C (max. 24 h)
Ambient light immunity 70.000 lx
Tab. 17: Bulkscan LMS511 data sheet
11.2 Analog module BAM100 data sheet
Electric
Minimum Typical Maximum
Power supply 20.4 V DC 24 V DC 28.8 V DC
Current consumption max. 320 mA
Inrush current 2,5 x current consuption
Recommended fuse <= 10 A
Power contacts 24 VDC max /
10 A max.
Isolation 500 V
Connection Bulkscan 1 x RJ45
Transfer rate 10/100 Mbaud
Cable length between Bulkscan and
BAM100
100 m max.
Analog input 4 x 4…20 mA
Internal resistance < 85 Ohm
Resolution 12 Bit
Measurement error <+-0,3%ofnalvalue
Surge voltage resistance 30 V DC
Total response time Bulkscan and
BAM100
500 ms
Analog output 4 x 4…20 mA
Load < 350 Ohm (short-circuit protected)
Resolution 12 Bit
Measurement error <+-0,1%ofnalvalue
EMC EN 61000-6-2/EN 61000-6-4
Connection technology
Wiring Spring force tegnology Cage Clamp
Cross-sectional area 0,08 … 2,5 mm², wire massive / solid, AWG28-14
Stripping length 8 … 9 mm
Mechanical
Asembly on 35 mm mounting rail according to EN 50022
Material housing Polycarbonat
Dimensions (WxHxD) 86 mm x 100 mm x 68 mm
Weight 250 g
Encloser rate IP20
Installation position exible
