OPERATING INSTRUCTIONS| Bulkscan LMS5118014829/ZNC5/2017-06-06| SICK
Subject to change without notice
77
ORDERING INFORMATION
12 Ordering information
12.1 Scope of delivery
The Bulkscan delivery includes the following components:
Piece Components Comment
1 LaservolumeowmeterBulk-
scan LMS51120190
Consisting of:
Sensor head with opto-electronic acquisition
system (housing)
Application module (already mounted)
Systemplugwithcongurationmemory(already
mounted, contains all electrical connections)
1 Device instructions with electri-
cal circuit diagram
Included in the Bulkscan LMS511 packaging
Tab. 18: Scope of delivery
12.2 Accessories
Part Description Part number
BAM100 Analogue module, Fa. Beckhoff, Power supply: 24
V DC (-15%/+20%), Din rail module, 35 mm C-rail,
acc. EN50022, Encloser rate IP20, Ethernet TCP/
IP interface (RJ45), CoLA Communication, Analog
signals:3 x IN: 4 ... 20 mA, 4 x OUT: 4 ... 20 mA
2073296
Measuring wheel en-
coder with open cable
Measuring wheel DFV60E-22EK01024
Cable, 1.5 m, 8-pin
Surface: O-ring
Measuring wheel circumference: 300 mm
Number of lines: 1024
Encoder resolution: 0.293 mm/Inc
Temperature range: - 20 … 100 ° C
1060309
Spring arm for measur-
ing wheel encoder
DFV60 spring arm
For connection with measuring wheel encoder of
type DFV60 (1060308 and 1060309)
2056155
Incremental encoder
with solid shaft
Incremental encoder DFS60E-S4EK01024
Cable, 8-wire universal, 1.5 m
Number of lines: 1024
Temperature range: 0 to 85 °C
Measuring wheel must be ordered separately
1037534
Measuring wheel for
encoder shafts
Measuring wheel for incremental encoders of type
DFS60 (1037534)
Surface: Hytrel, smooth surface
Measuring wheel circumference: 200 mm
Encoder resolution: 0.195 mm/Inc
5312988
Measuring wheel for
encoder shafts
Measuring wheel for incremental encoders of type
DFS60 (1037534)
Surface: Hytrel, smooth surface
Measuring wheel circumference: 500 mm
Encoder resolution: 0.488 mm/Inc
5312989
