SICK Bulkscan LMS511 User Manual

OPERATING INSTRUCTIONS | Bulkscan LMS511 8014829/ZNC5/2017-06-06 | SICK
Subject to change without notice
44
ELECTRICAL INSTALLATION
24 V EXT
OUT3 … OUT6
GND EXT
SPS
Bulkscan
Fig. 27: Connecting the outputs to a PLC (active HIGH)
6.3.6 Analog inputs/outpus with analog module BAM100
6.3.6.1 Module design
Fig. 28: module design
Do not dismount terminals of the module
Order Marking
1 BC9050 (bus terminal)
2 KL3454 (3 analog input)
3 KL4424 (4 analog output)
4 KL9010 (end terminal)
1 2 3 4
Note
