13.1.11 Digital outputs
Permissible commands: sRN, sWN
Variable name Description Variable
type
Value range Unit
out1Assignment
out2Assignment
out3Assignment
out4Assignment
out5Assignment
out6Assignment
Assignment of the
digital outputs (1
to 6)
uint_8 0: Off
1: Information/
warnings
2: Volume quota
3: Mass quota
4:Volumeowrate
5:Massowrate
6: Center of gravity
7: Bulk height
8: Bulk density
9: Belt speed
DO1Logic
DO2Logic
DO3Logic
DO4Logic
DO5Logic
DO6Logic
Logic of the digital
outputs (1 to 6)
uint_8 0: Active high
1: Active low
outVolumeQuota
Volume quota per
pulse
oat_32 0.01 to 10
6
m³/Inc
outMassQuota
Mass quota per pulse oat_32 0.01 to 10
6
t/Inc
Variable name Description Variable type Value range Unit
outVolumeFlow
Volumeowrate
Parameter Variable type Value range Unit
Lower limit oat_32 –10
6
to 10
6
m³/h
Upper limit oat_32 –10
6
to 10
6
m³/h
Lower hysteresis oat_32 5 to 95 %
Upper hysteresis oat_32 5 to 95 %
outMassFlow
Massowrate
Parameter Variable type Value range Unit
Lower limit oat_32 –10
6
to 10
6
t/h
Upper limit oat_32 –10
6
to 10
6
t/h
Lower hysteresis oat_32 5 to 95 %
Upper hysteresis oat_32 5 to 95 %
