OPERATING INSTRUCTIONS| Bulkscan LMS5118014829/ZNC5/2017-06-06| SICK
Subject to change without notice
85
APPENDIX
Variable name Description Variable
type
Value range Unit
LICencset
Encoder: Direction uint_8 1: None (ENC1)
2: Over phase
(ENC1, ENC2)
3: Over level
(ENC1, ENC2)
aiBeltSpeedMin
Belt speed (4 mA point) oat_32 –30 to +30 m/s
aiBeltSpeedMax
Belt speed (20 mA point) oat_32 –30 to +30 m/s
parDensitySource
Bulk density: Source uint_8 0: Fixed value
1: Analog value
2: Measured value
parFixedDensity
Bulkdensity(xedvalue) oat_32 0 to 50 t/m³
aiDensityMin
Bulk density (4 mA point) oat_32 0 to 50 t/m³
aiDensityMax
Bulk density (20 mA
point)
oat_32 0 to 50 t/m³
parMassFlowSource
Massowrate:Source uint_8 0: Fixed value
1: Analog value
2: Measured value
parFixedMassFlow
Massowrate(xed
value)
oat_32 0 to 10
6
t/h
aiMassFlowMin
Massowrate(4mA
point)
oat_32 0 to 10
6
t/h
aiMassFlowMax
Massowrate(20mA
point)
oat_32 0 to 10
6
t/h
parHeightStrategy
Bulk height: Strategy uint_8 0: Center point
1: Highest point
parAveragingFlow
Averaginglter:Flow oat_32 0 to 3,600 s
parAveragingGravity
Averaginglter:Centerof
gravity
oat_32 0 to 3,600 s
parAveragingHeight
Averaginglter:Bulk
height
oat_32 0 to 3,600 s
parAveragingEdge-
Distance
Averaginglter(bulk
edge and belt edge)
oat_32 0 to 3,600 s
13.1.8 System
Permissible commands: sRN, sWN
Variable name Description Variable type Value range Unit
parVibrationTolerance
Tolerance against vibration unit_16 0 to 100 %
parReectionTolerance
Toleranceagainstreection unit_16 0 to 100 %
parParticleFilter
Optimization for outdoor
applications (measuring
mode)
bool_1 0: Deactivated
1: Active
parInvSpotsToZero
Ignore measurement points
below the reference contour:
Activate
bool_1 0: Deactivated
1: Active
parThreshold2Zero
Ignore measurement points
below the reference contour:
Threshold
uint_32 0 to 10,000
