APPENDIX
Variable name Description Variable type Value range Unit
ccMeasArea1
ccMeasArea2
ccMeasArea3
ccMeasArea4
ccMeasArea5
ccMeasArea6
ccMeasArea7
ccMeasArea8
ccMeasArea9
ccMeasArea10
Measured area (reference
measurement 1 to 10)
oat_32 m
2
ccRefArea1
ccRefArea2
ccRefArea3
ccRefArea4
ccRefArea5
ccRefArea6
ccRefArea7
ccRefArea8
ccRefArea9
ccRefArea10
Reference area (reference
measurement 1 to 10)
oat_32 m
2
Permissible commands: sRN, sWN
Variable name Description Variable type Value range Unit
ccRefVolume1
ccRefVolume2
ccRefVolume3
ccRefVolume4
ccRefVolume5
ccRefVolume6
ccRefVolume7
ccRefVolume8
ccRefVolume9
ccRefVolume10
Reference volume
(reference measurement 1
to 10)
oat_32 ≥0 m³
ccCoeff1
Quadraticcoefcientofthe
compensation function
oat_32
ccCoeff2
Linearcoefcientofthe
compensation function
oat_32
ccCoeff3
Constantcoefcientofthe
compensation function
oat_32
ccPolyDegree
Polynomial degree for calcu-
lation of the compensation
function
uint_8 0: linear
1: square
Permissible commands: sMN
Method name Description
ccStart
Start reference measurement
ccStop
Stop reference measurement
ccClearLast
Delete last reference measurement
ccCalculate
Calculate compensation function
