Product description
2.1
System overview, functional principle
2.1.1 System overview
 FLSE200 sender/receiver unit
for transmitting and receiving ultrasonic pulses
 Bracket for FLSE200
for mounting the sender/receiver units on the tunnel wall
 MCU control unit
For control, evaluation and output of data of sensors connected via RS485 interface
 Connection cable
Junction box for connection cable
 Connection cable to connect the FLSE200 to the junction box
Fig. 1 FLOWSIC200 system components
Tak
-40°
60°
18,7°
SOPAS ET
Sender/receiver unit Slave Connection cable
Tunnel
Sender/receiver unit Master Junction box MCU

t
r
t
v
Flow direction
