Commissioning and parameterization
4.4.3.2
Sender/receiver units
The following steps are required to enter the system data:
 Set the sender/receiver units to “Maintenance” and select the “Parameter” submenu.
 Select the parameter to be set and enter the default password “1234”.
 Set the application-specific values (  p. 71, §4.2.4) with buttons “^“ and/or “→“ and
write to the device with “Save“ (confirm twice).
Fig. 90 Menu structure for parameterization
Back Enter
1 Path length
2 Installation angle
3 Cross Section Area
Parameter
//paramsensor/1
Back Save
Back Save
Back Save
Back Save
Back Save
Back Save
000.000 °
000.000 m
00000.0 m²
045.000 °
025.451 m
Min: 0.00
Max: 100.00
Min: 0.00
Max: 100.00
00075.0 m²
Parameter
Parameter
Parameter
Parameter
Parameter
Parameter
Back Save
Password
XXXX
Parameter
Back Save
Back Save
Password
XXXX
Password
XXXX
Parameter
Parameter
Min: 0.05
Max: 089.00
Min: 0.05
Max: 089.00
Min: 0.10
Max: 1000.00
Min: 0.10
Max: 1000.00
