2.2.5 Mounting kit
Various mounting kits are available for mounting the bracket assemblies for the sender/
receiver unit and junction box on the tunnel wall or ceiling. Selection depends on the actual
requirements. The Table below lists the respective parts and their usage options.
Mounting kit Usage
Designation
(Part No.)
Components Requirements For component Qty. per
comp.
2D8-1.4571/PA
(2031888)
–2x Fischer dowel S10
– 2x hexagon wood-
screw 8*50 A4
No
special
– Bracket for FLSE200-M
– Bracket for FLSE200-HM
– Bracket for FLSE200-H
1
2M8-1.4571
(2031891)
–2x dowel SLM 8N A4
– 2x hexagon screw
8*55 A4
Stainless steel
only
– Bracket for FLSE200-M
– Bracket for FLSE200-HM
– Bracket for FLSE200-H
1
– Junction box in stainless
steel housing
2
2M8-1.4529
(2031886)
2x Fischer tie bolt FAZ
8/10 C
Aggressive
ambient air
– Bracket for FLSE200-M
– Bracket for FLSE200-M
Material 1.4529
– Bracket for FLSE200-HM
– Bracket for FLSE200-H
– Bracket for FLSE200-H and
FLSE200-HM 1.4529
1
4D8-1.4571/PA
(2031889)
–4x Fischer dowel S10
– 4x hexagon wood-
screw 8*50 A4
No
special
– Junction box in stainless
steel housing
1
2D4-1.4571/PA
(2031890)
–2x Fischer dowel S6
– 2x round head wood-
screw 3.5*40 A4
–Junction box 1
4M8-1.4529
(2031887)
4x Fischer tie bolt FAZ
8/10 C
Aggressive
ambient air
– Junction box in stainless
steel housing
1
