Specification
FLOWSIC200 · Operating Instructions · 8013271/1CJ9/V2-0/2022-01 · © SICK Engineering GmbH 113
7.2
Dimensions, Part Nos.
All dimensions are in mm.
7.2.1 Sender/receiver units
FLSE200-M
Fig. 96 FLSE200-M sender/receiver unit
120
> 150
Ø 34
60 45
60
80
40
Designation Quantity Part No.
FLSE200-M sender/receiver unit 2 1044804
