52 FLOWSIC200 · Operating Instructions · 8013271/1CJ9/V 2-0/2022-01 · © SICK Engineering GmbH
Assembly and installation
1)
: Closed in currentless condition (normal closed)
2)
: Open in currentless condition (normal open)
3)
: Only use after agreement with manufacturer
Analog input a in 1 25
gnd 26
a in 2 27
gnd 28
Connections for sender/receiver unit, Master +24 31 (36)
-24 32 (37)
RS485 A 33 (38)
RS485 B 34 (39)
scr. 35 (40)
Input voltage supply 24V DC
3)
24 V 41
gnd 42
Output voltage supply 24 V DC
3)
24 V 43
gnd 44
Input 30 V electr. isolated + 45
-46
RS232/485
3)
tx/A 51
rx/B 52
gnd 53
Interface 1 A 71
B72
gnd 73
+Us 74
-Us 75
gnd 76
imp+ 77
imp- 78
res 1 79
res 2 80
Function Connection Terminal No.
