ONLINE HELP SOPAS Chapter 5
LECTOR®620
Parameters
8013778/Y269/2013-11-27 © SICK AG · Germany · All rights reserved · Subject to change without notice 87
Y3 - Code corner 3 Y Pixel position of code corner 3Y
X4 - Code corner 4 X Pixel position of code corner 4X
Y4 - Code corner 4 Y Pixel position of code corner 4Y
CPX - X position relative to image origin Code center X in pixels
CPY - Y position relative to image origin Code center Y in pixels
AN2 - Tilt angle Tilt angle for 1D codes and 2D codes relative to
the horizontal (angular degree)
MCR - Ratio between image and multicount [in
%]
Ratio between images and successful multi-
reads
X2D - X 2D Symbol size (number of modules) in X direction;
for 2D codes only
Y2D - Y 2D Symbol size (number of modules) in Y direction;
for 2D codes only
MX2 - Modul X size Average modul size in X direction in mm; for 2D
codes only
MY2 - Modul Y size Average modul size in Y direction in mm; for 2D
codes only
IV2 - Inverse (boolean) Code was read inverted
MD2 - Mirrored (boolean) Code was read mirrored
CTG - ISO16022/ISO15415 Symbol contrast
grade
Grading for symbol contrast according to ISO/
IEC16022 and ISO/IEC15415. Checks the con-
trast between brigth and dark dots in the code.
CTG - ISO16022/ISO15415 Symbol contrast
value
Value for symbol contrast according to ISO/
IEC16022 and ISO/IEC15415. Checks the con-
trast between brigth and dark dots in the code.
More… Description
PGV - ISO16022/ISO15415 Print growth value Grading for print growth according to ISO/
IEC16022 and ISO/IEC15415. Checks the diffe-
rence between the ideal and the actual dot size.
PGG - ISO16022/ISO15415 Print growth grade Value for print growth according to ISO/
IEC16022 and ISO/IEC15415. Checks the diffe-
rence between the ideal and the actual dot size.
ANUV - ISO16022/ISO15415 Axial non-unifor-
mity value
Value for axial non-uniformity according to ISO/
IEC16022 and ISO/IEC15415. Checks the ration
between length and width of the code. If the
code is streched or compressed in length or
width, it is given a poor rating for its axial non-
linearity.
ANUG - ISO16022/ISO15415 Axial non-unifor-
mity grade
Grading for axial non-uniformity according to
ISO/IEC16022 and ISO/IEC15415. Checks the
ration between length and width of the code. If
the code is streched or compressed in length or
width, it is given a poor rating for its axial non-
linearity.
UECV - ISO16022/ISO15415 Unused error cor-
rection value
Value for unused error correction according to
ISO/IEC16022 and ISO/IEC15415. Checks how
much redundant data had to be used during rea-
ding to decode the data content. The best grade
is achieved if redundancy was not required at all.
More code-realted items… Description
