Chapter 5 ONLINE HELP SOPAS
LECTOR®620
88 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013778/Y269/2013-11-27
Parameters
UECG - ISO16022/ISO15415 Unused error cor-
rection grade
Grading for unused error correction according to
ISO/IEC16022 and ISO/IEC15415. Checks how
much redundant data had to be used during rea-
ding to decode the data content. The best grade
is achieved if redundancy was not required at all.
OSG - Overall symbol grade Overall symbol grade according to ISO/
IEC16022 and ISO/IEC15415. This grading can
be considered as a summary of the criteria. The
poorest af all the criteria used is always output.
GNUV - ISO15415 Grid non-uniformity value Grading for grid non-uniformity according to ISO/
IEC15415. A grid is placed over the code using
the alternating pattern to locate the scan points
for decoding. Grid non-uniformity checks the
extent to which the grid deviates from the ideal
grid.
GNUG - ISO15415 Grid non-uniformity grade Value for grid non-uniformity according to ISO/
IEC15415. A grid is placed over the code using
the alternating pattern to locate the scan points
for decoding. Grid non-uniformity checks the
extent to which the grid deviates from the ideal
grid.
MODV - ISO15415 Modulation value Value for modulation according to ISO/
IEC15415. Checks uniformity of the reflectance
of dark and light dots.
MODG - ISO15415 Modulation grade Grading for modulation according to ISO/
IEC15415. Checks uniformity of the reflectance
of dark and light dots.
FPDV - ISO15415 Fixed pattern damage value Value for fixed pattern damage according to ISO/
IEC15415. Checks the fundamental characteri-
stics of the code (quiet zone, finder, alternating
patterns and reference dots) for defects and cal-
culates an average.
FPDG - ISO15415 Fixed pattern damage grade Grading for fixed pattern damage according to
ISO/IEC15415. Checks the fundamental charac-
teristics of the code (quiet zone, finder, alterna-
ting patterns and reference dots) for defects and
calculates an average.
EC - ECC level Specific DMX quality value
ECCW - ECC code words Number of read code modules for Reed-Solo-
mon-Error correction
DCW - Data code words Number of code data modules
NEC - Num. ECC correctables Number of correctable code modules in case of
damage
NEE - Num. of ECC errors Number of incorrect code modules
NES - Num. of ECC erasures Number of incorrect code modules with known
position
MC - Multi Count. Indicates how often a code was read within a
reading gate (Codes are not displayed separa-
tely!)
DLSZ - Number of devices Number of connected devices
DLCS - Device list separated by comma List of connected devices separated by comma
DLBS - Device list separated by blank List of connected devices separated by blank
