7.2.6.2 Open the device window – configure devices
Overview
T
o configure the device, perform diagnostics or create reports, open a device window.
Approach
Y
ou have the following options:
►
Double-click on the Device tile.
Or:
►
Open t
he tile menu and choose Configure.
✓
The device window opens.
Complementary information
W
hen a device is configured offline for the first time, the device selection wizard opens
for devices with multiple variants (device types). This is where you select the exact type
of device to be configured.
7.2.6.3 Type code in Safety Designer
The Safety Designer displays a separate type code for the device with system plug,
whic
h differs from the type code for the device without system plug.
Table 12: Type code in Safety Designer
Device System plug Device with system plug
Performance package Type code Connections Type code Type code
Pro – EtherNet/IP™ NANS3-CAAZ30IZ1
•
C
able with plug con‐
nector
•
Cable with M12 net‐
work connection
NANSX-AAAAAEZZ1 NANS3-CAAZ30IZ1P02
7 CONFIGURATION
