● Edge Type
Shows the type of the connection. The following values are possible:
– Edge Port
An edge port is connected to this port.
– No Edge Port
There is a spanning tree or rapid spanning tree device at this port.
● P.t.P. Type
Shows the type of the point-to-point link. The following values are possible:
– P.t.P.
With half duplex, a point-to-point link is assumed.
– Shared Media
With a full duplex connection, a point-to-point link is not assumed.
Note
Point-to-point link means a direct connection between two devices. A shared media
connection is, for example, a connection to a hub.
6.4.8 Ethernet Statistics
6.4.8.1 Interface Statistics
The page shows the statistics from the interface table of the Management Information Base
(MIB).
Configuring with Web Based Management
6.4 "Information" menu
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
Configuration Manual, 11/2019, C79000-G8976-C485-03 103
