Note
The ASCII code 0x20 to 0x7e is used in the input boxes.
Procedure
1. Enter the contact person responsible for the device in the "System Contact" input box.
2. Enter the identifier for the location at which the device is installed in the "System Location"
input box.
3. Enter the name of the device in the "System Name" input box.
4. Click the "Set Values" button.
6.5.2.2 Coordinates
Information on geographic coordinates
In the "Geographic Coordinates" window, you can enter information on the geographic
coordinates. The parameters of the geographic coordinates (latitude, longitude and the height
above the ellipsoid according to WGS84) are entered directly in the input boxes of the
"Geographic Coordinates" window.
Getting the coordinates
Use suitable maps for obtaining the geographic coordinates of the device.
The geographic coordinates can also be obtained using a GPS receiver. The geographic
coordinates of these devices are normally displayed directly and only need to be entered in the
input boxes of this page.
Configuring with Web Based Management
6.5 "System" menu
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
144 Configuration Manual, 11/2019, C79000-G8976-C485-03
