● P.t.P.
– Enabled
Shows that a point-to-point link exists.
– Disabled
Shows that no point-to-point link exists.
● Hello Time
Enter the interval after which the bridge sends configuration BPDUs. As default, 2 seconds
is set.
Range of values: 1-2 seconds
Note
The port-specific setting of the Hello time is only possible in MSTP compatible mode.
Procedure
1. In the input cells of the table row, enter the values of the port you are configuring.
2. From the drop-down lists of the cells of the table row, select the values of the port you are
configuring.
3. Click the "Set Values" button.
6.7.3.4 MST General
Multiple Spanning Tree configuration
With MSTP, in addition to RSTP, several VLANs can be managed in a LAN with separate RSTP
trees.
Configuring with Web Based Management
6.7 "Layer 2" menu
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
276 Configuration Manual, 11/2019, C79000-G8976-C485-03
