● Link
Shows the connection status to the network. With the connection status, the following is
possible:
– up
The port has a valid link to the network, a link integrity signal is being received.
– down
The link is down, for example because the connected device is turned off.
● Current Transmission Parameters
Shows the transfer parameters of the port.
● Negotiation
Shows whether the automatic configuration is enabled or disabled.
● MAC Address
Shows the MAC address of the port.
6.6.1.2 Configuration
Configuring ports
With this page, you configure the Ethernet ports of the device.
Configuring with Web Based Management
6.6 "Interfaces" menu
SCALANCE W1780/W1740 according to IEEE 802.11ac Web Based Management
220 Configuration Manual, 11/2019, C79000-G8976-C485-03
